Electric chain hoist HHBD 0.5 t, 12 m
The HHBD electric hoist is a reliable, modern professional hoist that does not use a rope to lift objects, but a steel hoist chain. Advantages of the HHBD-T hoist compared to wire rope hoists: compactness, no drum, easy installation, long chain life, no load deviation, easy chain change. The standard version of the HHBD-T is equipped with a trolley with an electric drive, so it can be mounted on the I-section of the appropriate number and move the elevator and loads in the horizontal plane.
Additional specifications on request.
The HHBD electric hoist is a reliable, modern professional hoist that does not use a rope to lift objects, but a steel hoist chain. Advantages of the HHBD-T hoist compared to wire rope hoists: compactness, no drum, easy installation, long chain life, no load deviation, easy chain change. The standard version of the HHBD-T is equipped with a trolley with an electric drive, so it can be mounted on the I-section of the appropriate number and move the elevator and loads in the horizontal plane.
| Dimensions, mm | 460x780x380 |
| Pulley type | electric |
| Height, mm | 630 |
| Movement speed, m / min | 15 |
| Lifting speed, m / min | 6,8 |
| Chassis motor, kW | 0.4 |
| Remote control cable length, m | 10.5 |
| Movement type | mobile |
| Voltage, V | 380 |
| Load capacity, kg | 500 |
| Lifting height, mm | 12000 |
| Weight (KG) | 86.00 |
Additional specifications on request.
